Title: Allen-Bradley PanelView 600 2711-K6C10 HMI Terminal - 5.7-inch Color Keypad Operator Interface

Product Overview:
The Allen-Bradley PanelView 600 2711-K6C10 is a robust and reliable Human Machine Interface (HMI) terminal designed for industrial automation applications. As part of the highly successful PanelView 600 Standard series, this operator interface provides a crucial link between operators and machinery, enabling efficient control, monitoring, and data visualization in diverse manufacturing environments. Featuring a vibrant 5.7-inch color display and a durable keypad for precise input, the 2711-K6C10 is engineered to withstand harsh industrial conditions while offering clear, real-time operational insights. Its proven performance and seamless integration capabilities with Allen-Bradley PLCs via RS-232 (DF1) communication make it an ideal choice for upgrading existing systems or implementing new control solutions that demand high reliability and intuitive operator interaction. This HMI enhances productivity by providing operators with immediate access to critical process information and control functions, minimizing downtime and optimizing operational efficiency.

Key Features & Benefits:

5.7-inch Color TFT LCD Display: Provides clear, crisp, and vibrant visual feedback for complex process graphics, alarms, and data trends, improving operator comprehension and decision-making.
Integrated Keypad Input: Features dedicated function keys, numeric keys, and navigation keys, offering tactile feedback and precise control, especially beneficial in environments where gloves are worn or touchscreens are impractical.
Robust Industrial Design: Built to withstand harsh industrial conditions, including temperature fluctuations, vibration, and shock, ensuring long-term reliability and performance in demanding applications.
NEMA 4X/IP65 Rated Front Panel: Offers superior protection against dust, dirt, and water ingress, making it suitable for washdown environments and challenging industrial settings.
RS-232 (DF1) Communication Port: Enables reliable and direct communication with Allen-Bradley SLC 500, MicroLogix, and ControlLogix PLCs, simplifying system integration and data exchange.
Non-Volatile Memory: Securely stores application programs and configuration data, ensuring data integrity even during power interruptions and reducing the need for frequent reprogramming.
PanelBuilder32 Software Compatibility: Allows for easy and intuitive development, configuration, and maintenance of HMI applications, streamlining the engineering process and reducing development time.
Enhanced Operator Efficiency: Provides a user-friendly interface for monitoring machine status, adjusting parameters, acknowledging alarms, and performing diagnostics, leading to reduced errors and improved operational flow.
Cost-Effective Solution: Offers a durable and long-lasting HMI solution that minimizes maintenance requirements and extends the lifespan of industrial control systems.

Applications:

Manufacturing and Assembly Lines: For machine control, process monitoring, and production data visualization.
Packaging and Material Handling: Managing conveyor systems, robotic cells, and automated storage and retrieval systems.
Water and Wastewater Treatment: Monitoring pump stations, flow rates, and chemical dosing processes.
Food and Beverage Processing: Controlling batch processes, recipe management, and sanitation cycles.
Automotive Industry: Interfacing with welding robots, paint booths, and assembly line automation.
Pharmaceutical and Life Sciences: Ensuring precise control and data logging for batch processing and cleanroom environments.
General Industrial Automation: Any application requiring a reliable and intuitive operator interface for real-time control and data display.

Technical Specifications:

Part Number: 2711-K6C10
Alternate Part Number: 2711K6C10
Series: PanelView 600 Standard
Display Type: Color TFT LCD
Display Size: 5.7 inches
Display Resolution: 320 x 234 pixels
Backlight Type: Cold Cathode Fluorescent Lamp (CCFL)
Input Method: Keypad (10 Function Keys, Numeric Keypad, Navigation Keys)
Communication Port: RS-232 (DF1 Protocol)
Power Input: 85-264V AC, 47-63 Hz
Enclosure Rating: NEMA 4X, IP65 (Front Panel)
Operating Temperature: 0°C to 50°C (32°F to 122°F)
Storage Temperature: -20°C to 70°C (-4°F to 158°F)
Relative Humidity: 5% to 95% non-condensing
Software Compatibility: PanelBuilder32
Weight: Approximately 2.0 kg (4.4 lbs)
