Product Overview:
The Azbil SDC26 is a state-of-the-art digital indicating controller engineered for unparalleled precision and reliability in a wide array of industrial process control applications. Featuring a high-visibility, multi-digit display and universal input capabilities, the SDC26 seamlessly integrates into complex systems, providing accurate measurement and sophisticated control of temperature, pressure, flow, and other critical process variables. Its robust design and advanced control algorithms, including PID and program control, ensure stable and efficient operation, making it an indispensable tool for optimizing productivity and maintaining stringent quality standards across various sectors. This versatile controller is designed for ease of use, offering intuitive setup and comprehensive monitoring functionalities, empowering engineers and operators with superior command over their processes. The Azbil SDC26 series is renowned for its durability and consistent performance, making it a preferred choice for demanding industrial environments where accuracy and reliability are paramount.


Technical Specifications:

Model Series: Azbil SDC26 Digital Indicating Controller
Part Number (Standard): SDC26C1000-00-00000
Part Number (Simplified): SDC26C10000000000
Control Type: PID Control, Program Control (Multi-Segment), ON/OFF Control, Heating/Cooling Control
Input Type: Universal Input - Thermocouple (K, J, T, E, R, S, B, N, W), RTD (Pt100, JPt100), DC Voltage (0-1V, 0-5V, 1-5V, 0-10V), DC Current (0-20mA, 4-20mA)
Output Options: Relay Contact Output (SPDT), SSR Drive Voltage Output (12V DC), DC Current Output (4-20mA DC), DC Voltage Output (0-5V DC, 1-5V DC, 0-10V DC)
Display: Dual 5-digit LED Display (Process Value PV - Red, Set Value SV - Green)
Control Accuracy: ±0.1% of full scale for analog inputs (typical), ±1 digit
Sampling Cycle: 0.25 seconds (250 ms)
Power Supply: 100-240V AC (50/60Hz) or 24V AC/DC (model dependent)
Power Consumption: Max. 10 VA (typical)
Communication Interface: RS-485 (Modbus RTU protocol)
Alarm Outputs: Up to 4 configurable alarm outputs (e.g., high/low limit, deviation, band, sensor break)
Operating Temperature: 0 to 50°C (32 to 122°F)
Operating Humidity: 10 to 90% RH (non-condensing)
Mounting: Panel Mount (Flush Mount)
Dimensions (H x W x D): Approximately 96 mm x 96 mm x 100 mm (3.78 in x 3.78 in x 3.94 in)
Panel Cutout: 92 mm x 92 mm (3.62 in x 3.62 in)
Weight: 0.65 kg (1.43 lbs)
Certifications: CE, UL/cUL recognized (model dependent), RoHS compliant
