Title: KEYENCE LS-5001 High-Accuracy Digital Laser Scan Micrometer for Precision Measurement

Product Overview:
The KEYENCE LS-5001 is a cutting-edge, ultra-high-speed, and exceptionally accurate digital laser scan micrometer engineered for precise non-contact measurement of outer diameters, gaps, and positions. This advanced optical measurement system leverages state-of-the-art technology to deliver unparalleled measurement stability, repeatability, and reliability, making it an indispensable tool for demanding industrial applications where micron-level precision is paramount. Designed for seamless integration into automated production lines and rigorous quality control environments, the LS-5001 significantly enhances measurement throughput, reduces inspection time, and contributes directly to improved product quality and operational efficiency. Its robust construction ensures consistent performance even in challenging manufacturing conditions, providing a long-term solution for critical dimension verification.

Key Features & Benefits:

Ultra-High-Speed Sampling: Achieves industry-leading sampling rates up to 64,000 samples/sec, enabling precise and stable measurement of rapidly moving targets, vibrating objects, and high-speed production processes.
Sub-Micron Accuracy: Delivers exceptional measurement accuracy down to +/-0.05 µm, ensuring the highest level of precision for critical dimensions and tight tolerances.
Wide Measurement Range: Accommodates a broad spectrum of object sizes, typically from 0.01 mm up to 60 mm, providing versatile application capabilities across various industries.
Non-Contact Measurement: Eliminates the risk of damage, deformation, or contamination to delicate or sensitive workpieces, preserving product integrity and surface finish.
Advanced Optical System: Incorporates a high-resolution CCD and a stable, high-intensity laser source for consistent, reliable, and drift-free measurements, even in environments with temperature fluctuations or vibrations.
Robust Industrial Design: Built with a durable, IP64-rated enclosure for the sensor head, ensuring long-term reliability and minimal maintenance requirements in harsh factory conditions.
Easy Integration: Features multiple output options including digital I/O, analog output, and serial communication (RS-232C), facilitating seamless integration into existing PLCs, PCs, and automation systems.
Real-time Data Output: Provides instant measurement data for immediate process control, statistical process control (SPC), and quality assurance, enabling proactive adjustments.
User-Friendly Interface: Simplifies setup, calibration, and operation, reducing training time and improving overall productivity for operators and engineers.
High Repeatability: Guarantees consistent and reliable measurement results over extended periods, crucial for maintaining product quality standards and process stability.

Applications:

Precision manufacturing and machining for aerospace, automotive, and medical industries
Automated inspection of automotive components such as shafts, pins, engine parts, and brake lines
Quality control in medical device manufacturing for catheters, needles, stents, and surgical instruments
Continuous diameter measurement of wires, cables, optical fibers, and filaments during production
Dimensional inspection of electronic components including lead frames, connectors, and semiconductor wafers
In-line quality assurance for plastic and rubber extrusion processes (tubes, rods, profiles)
Measurement of bearing components, rollers, and precision mechanical parts
Research and development for new material characterization and product design validation
Gap and position measurement in assembly processes
Glass tubing and pharmaceutical vial dimensioning

Technical Specifications:

Part Number: LS-5001-P
Part Number (No Special Characters): LS5001P
Measurement Principle: Laser Scan Micrometer (Optical Scanning Method)
Measurement Range: 0.01 to 60 mm (0.0004 to 2.36 inches)
Resolution: 0.01 µm (0.0000004 inches)
Repeatability: +/-0.05 µm (typical, for static measurement)
Sampling Speed: Max. 64,000 samples/sec
Light Source: Visible Semiconductor Laser (IEC Class II / FDA Class II)
Output: Digital I/O, Analog Output (4-20mA / 0-10V), RS-232C
Power Supply: 24 VDC +/-10%
Current Consumption: Max. 1.5 A (Sensor Head and Controller combined)
Operating Temperature: 0 to 50 degrees C (32 to 122 degrees F)
Storage Temperature: -10 to 60 degrees C (14 to 140 degrees F)
Enclosure Rating: IP64 (Sensor Head)
Weight: Approximately 2.5 kg (Sensor Head)
