Product Overview: The Mitsubishi MR-J4-100B-RJ010 is a high-performance AC servo amplifier from the MELSERVO-J4 series, specifically designed for precise and dynamic motion control in advanced industrial automation systems. This 1.0 kW (1000W) servo amplifier operates on a three-phase 200V AC power supply and features the high-speed SSCNET III/H communication interface, which enables fully synchronized control systems with communication cycles as fast as 0.222 ms. It supports various control modes including position, speed, and torque, making it highly versatile for complex applications. The MR-J4-100B-RJ010 incorporates advanced features such as "One-Touch Tuning" for automatic servo gain adjustment, "Advanced Vibration Suppression Control II" to minimize low-frequency vibrations, and "Safe Torque Off (STO)" for enhanced safety. Its robust design and comprehensive protective functions ensure reliable, efficient, and highly accurate operation, contributing to improved machine performance and reduced commissioning time.
Technical Specifications:
- Part Number: MR-J4-100B-RJ010
- Alternative Part Number: MRJ4100BRJ010
- Manufacturer: Mitsubishi Electric
- Product Series: MELSERVO-J4 (MR-J4-B series)
- Type: AC Servo Amplifier / Servo Drive
- Rated Output Power: 1.0 kW (1000 W)
- Rated Output Current: 6.0 A
- Input Voltage (Main Circuit): 3-phase AC 200V to 240V, 50/60 Hz (permissible fluctuation: 170V AC to 264V AC)
- Input Voltage (DC Main Circuit): 283V DC to 340V DC
- Control Method: Sine-wave PWM control, current control method
- Control Modes: Position control, Speed control, Torque control
- Communication Interface: SSCNET III/H (high-speed serial communication)
- Communication Cycle: 0.222 ms, 0.444 ms, 0.888 ms
- Motor Feedback: High-resolution absolute position encoder (4,194,304 pulses/rev, 22-bit)
- Safety Function: Safe Torque Off (STO) built-in (IEC/EN 61800-5-2, EN ISO 13849-1 PLe Cat3, IEC 62061 SILCL3)
- Dynamic Brake: Built-in
- Regenerative Resistor: Built-in
- Control Power Consumption: 30 W
- Protection Class: IP20
- Dimensions (W x H x D): 60 mm (2.36 in) x 168 mm (6.61 in) x 185 mm (7.28 in)
- Weight: Approximately 1.4 kg (3.09 lbs)
- Operating Temperature: 0 to +55 °C
- Storage Temperature: -20 to +65 °C
- Humidity: 90% RH or less (non-condensing)
- Certifications: CE, cULus, KC, EAC, TÜV Rheinland
- Product Lifecycle: Standard selling status.
MITSUBISHI MR-J4-100B-RJ010
