Product Overview:
The SEIKI PSO-LCD 10-24-00, when integrated with the SEIKI POS-M 10-22-01, constitutes a state-of-the-art spindle orientation and position control system engineered for the most demanding industrial automation and machine tool applications. This powerful combination delivers unparalleled accuracy and repeatability in precisely stopping and orienting machine spindles, which is absolutely critical for optimizing processes such as automatic tool changes, robotic part loading/unloading, and specialized machining operations including tapping, boring, and gear cutting. Designed for robust performance and long-term reliability in harsh manufacturing environments, this SEIKI system significantly enhances overall machining accuracy, improves surface finish quality, and extends the operational lifespan of cutting tools. Its intuitive LCD interface simplifies programming and real-time monitoring, while the dedicated position module ensures consistent, high-precision results, making it an essential component for modern CNC machines aiming to maximize productivity and minimize downtime.


Technical Specifications:

 Part Number (PSO-LCD): SEIKI PSO-LCD 10-24-00
 Part Number (PSO-LCD - No Special Characters): SEIKI PSOLCD 102400
 Part Number (POS-M): SEIKI POS-M 10-22-01
 Part Number (POS-M - No Special Characters): SEIKI POSM 102201
 System Type: Programmable Spindle Orientation and Position Control System
 Display: Integrated LCD (Liquid Crystal Display) for user interface and status indication
 Input Power: Typically 24 VDC (Control Logic Power Supply)
 Output Signals: Configurable Digital I/O, Relay Outputs for machine control
 Orientation Accuracy: +/- 0.1 degree (typical, dependent on mechanical setup and application)
 Orientation Speed: Up to 360 degrees/second (dependent on spindle motor and drive capabilities)
 Operating Temperature: 0°C to 50°C (32°F to 122°F)
 Storage Temperature: -20°C to 70°C (-4°F to 158°F)
 Relative Humidity: 5% to 95% non-condensing
 Mounting: Panel Mount (PSO-LCD) / DIN Rail Compatible (POS-M)
 Dimensions (PSO-LCD, approximate): 200mm (Height) x 150mm (Width) x 80mm (Depth)
 Dimensions (POS-M, approximate): 100mm (Height) x 70mm (Width) x 30mm (Depth)
 Total System Weight: 3.5 kg (7.7 lbs)
 Communication Interface: RS-232 / Parallel I/O (Common for industrial control systems)
 Protection Rating: IP20 (Typical for internal control components, suitable for enclosure mounting)
