Title: Siemens SINAMICS S120 Active Line Module 6SN1118-0NJ01-0AA1 - High Performance Power Regeneration

Product Overview: The Siemens SINAMICS S120 Active Line Module (ALM) 6SN1118-0NJ01-0AA1 is a crucial component for advanced industrial drive systems, designed to deliver unparalleled power quality and energy efficiency. As part of the renowned SINAMICS S120 family, this Active Line Module provides a sophisticated solution for converting AC line voltage into a regulated DC link voltage, while simultaneously offering regenerative feedback capabilities. It ensures a stable and clean power supply for connected motor modules and motors, significantly reducing harmonic distortion on the mains and improving overall system performance. Ideal for demanding applications requiring precise control, high dynamics, and energy recovery, the 6SN1118-0NJ01-0AA1 enhances the reliability and sustainability of your automation processes. This module is engineered for robust operation in challenging industrial environments, ensuring maximum uptime and long-term cost savings through its energy-efficient design and advanced power management features.

Key Features & Benefits:

Superior Power Quality: Actively compensates for harmonics and reactive power, ensuring a near-sinusoidal current draw from the mains and a power factor close to 1, minimizing grid disturbances.
Energy Regeneration: Capable of feeding braking energy back into the power grid, leading to significant energy savings and reduced operational costs, especially in applications with frequent braking or lowering cycles.
Stable DC Link Voltage: Maintains a constant and regulated DC link voltage, providing optimal operating conditions for connected motor modules and ensuring consistent, high-precision drive performance.
Grid-Friendly Operation: Minimizes mains perturbations and complies with stringent international standards for harmonic emissions (e.g., IEEE 519, EN 61000-3-2/12), reducing the need for external line reactors and filters.
High Efficiency: Designed for maximum energy conversion efficiency, reducing heat dissipation and contributing to a cooler, more reliable control cabinet environment, extending component lifespan.
Robust Industrial Design: Built to withstand harsh industrial environments, offering high reliability and a long service life, minimizing downtime and maintenance requirements.
Seamless Integration: Fully compatible with the Siemens SINAMICS S120 modular drive system, allowing for flexible and scalable solutions that adapt to evolving application needs.
Enhanced System Dynamics: Supports highly dynamic drive applications by providing rapid energy exchange between the drive system and the power grid, enabling quick acceleration and deceleration.
Integrated Protection Functions: Features comprehensive protection against overcurrent, overvoltage, undervoltage, and overtemperature, safeguarding both the module and connected equipment from potential damage.
Compact Footprint: Optimized design for space-saving installation in control cabinets, allowing for higher power density in industrial setups.

Applications:

High-performance machine tools (CNC machines, grinding machines, milling machines)
Printing and paper processing machines (web presses, sheet-fed presses)
Textile machinery (spinning, weaving, finishing, knitting machines)
Cranes, hoists, and material handling systems (stacker cranes, conveyor systems)
Test benches and simulation systems (automotive, aerospace, industrial testing)
Packaging and bottling machines (fillers, sealers, palletizers)
Robotics and automation cells (industrial robots, pick-and-place systems)
Extruders and plastic processing machinery (injection molding machines)
General industrial automation requiring precise motion control, high dynamics, and energy efficiency

Technical Specifications:

Part Number: 6SN1118-0NJ01-0AA1
Alternative Part Number: 6SN11180NJ010AA1
Product Type: Active Line Module (ALM)
Series: Siemens SINAMICS S120
Input Voltage: 3 AC 380-480 V (+10%/-15%)
Input Frequency: 50/60 Hz
Continuous Output Power: 10 kW
Peak Output Power: 16 kW (for 60s)
Continuous Output Current: 24 A
Peak Output Current: 36 A (for 60s)
Efficiency: >97% (typical)
Cooling Method: Internal air cooling
Protection Class: IP20
Operating Temperature: 0 to +50 °C
Storage Temperature: -25 to +70 °C
Relative Humidity: 5 to 95% (non-condensing)
Weight: 7.5 kg
Dimensions (H x W x D): 380 mm x 100 mm x 270 mm (approximate)
Mounting Position: Vertical
Certifications: CE, UL, cUL (where applicable)
