Title: Yaskawa CIMR-15AS2 J1000 Series Variable Frequency Drive (VFD) - 1.5kW (2HP) Single Phase 200-240V AC Inverter

Product Overview:
The Yaskawa CIMR-15AS2 is a high-performance, compact Variable Frequency Drive (VFD) from the renowned J1000 series, engineered to provide precise and efficient motor control for a wide range of industrial applications. This 1.5kW (2HP) single-phase inverter operates on 200-240V AC input, making it an ideal solution for small to medium-sized machinery requiring reliable speed and torque regulation. Designed with user-friendliness and energy efficiency in mind, the CIMR-15AS2 offers a cost-effective way to optimize motor performance, reduce energy consumption, and extend equipment lifespan. Its robust construction and advanced control algorithms ensure stable operation even in demanding environments, making it a preferred choice for system integrators, machine builders, and maintenance professionals seeking a dependable AC drive solution.

Key Features & Benefits:

Energy Efficiency: Advanced control algorithms and built-in PID functionality optimize motor operation, significantly reducing energy consumption and lowering operational costs for fans, pumps, and general machinery.
Compact Design: Its ultra-compact footprint allows for easy integration into control panels with limited space, maximizing panel efficiency and reducing overall system size.
Simple Setup and Operation: Features like the intuitive programming interface, parameter copy function, and quick setup wizard enable rapid commissioning and minimize installation time.
High Performance Control: Offers versatile control methods including V/f control and open-loop vector control, providing precise speed regulation and high starting torque for various load types.
Integrated Protective Functions: Comprehensive protection features such as overcurrent, overvoltage, undervoltage, overload, and motor thermal protection ensure safe and reliable operation of both the drive and the connected motor.
Built-in RS-485 Communication: Supports Modbus RTU protocol, facilitating seamless integration into existing automation networks and enabling remote monitoring and control.
Quiet Operation: Utilizes advanced PWM control technology to minimize motor noise, contributing to a more comfortable working environment.
Long Lifespan Components: Designed with high-quality, durable components for extended service life and reduced maintenance requirements, ensuring long-term reliability.
Removable Terminal Block: Simplifies wiring and maintenance tasks, allowing for quick and easy installation and troubleshooting.
Global Compliance: Meets international standards including CE, UL, and cUL, ensuring suitability for global deployment and adherence to safety regulations.

Applications:

The Yaskawa CIMR-15AS2 VFD is highly versatile and suitable for a broad spectrum of industrial and commercial applications, including but not limited to:
Fans and Blowers: For precise airflow control in HVAC systems, ventilation, and exhaust applications.
Pumps: Ideal for water supply, wastewater treatment, irrigation, and chemical dosing systems, optimizing flow and pressure.
Conveyor Systems: Provides smooth acceleration and deceleration, reducing mechanical stress and improving material handling efficiency.
Small Machine Tools: Enhances precision and control for lathes, milling machines, and grinders.
Packaging Machinery: Improves throughput and accuracy in labeling, filling, and sealing equipment.
Food Processing Equipment: Ensures hygienic and precise control for mixers, blenders, and conveyors in food and beverage industries.
Textile Machinery: Offers reliable speed control for spinning, weaving, and dyeing processes.
Woodworking Machinery: Provides consistent performance for saws, routers, and sanders.
General Industrial Automation: Suitable for a wide array of constant and variable torque applications where energy savings and precise control are critical.

Technical Specifications:

Model: YASKAWA CIMR-15AS2 (J1000 Series)
Part Number (with special characters): CIMR-15AS2
Part Number (without special characters): CIMR15AS2
Power Rating: 1.5 kW (2 HP)
Input Voltage: Single Phase 200-240 VAC (+10% / -15%)
Input Frequency: 50/60 Hz (±5%)
Output Voltage: 3 Phase 200-240 VAC (Proportional to input voltage)
Output Current: 8.0 A (Rated)
Output Frequency Range: 0.1 to 400 Hz
Control Method: V/f Control, Open Loop Vector Control
Overload Capacity: 150% for 60 seconds, 200% for 0.5 seconds
Braking Transistor: Built-in (for external braking resistor connection)
Communication Interface: RS-485 (Modbus RTU)
Enclosure Rating: IP20 (Open Type)
Operating Temperature: -10°C to +50°C (14°F to 122°F)
Storage Temperature: -20°C to +60°C (-4°F to 140°F)
Humidity: 20% to 90% RH (non-condensing)
Altitude: Up to 1,000 meters (3,300 feet) without derating
Cooling Method: Fan Cooled
Weight: 1.8 kg (Approximately 3.97 lbs)
Certifications: CE, UL, cUL
